Plant



CNC Turning Capacity

Hardinge Conquest GT c/w Fanuc 15 TF control

  • Capacity : 27mm (1.1/16") Barfeed
  • Barfeed : Sameca Monosam Hydraulic Barfeed System
  • Maximum speed : 6000 RPM
  • Accuracy : 5 microns

Hardinge Conquest 42. c/w Fanuc OTC control

  • Capacity : 42mm (1.5/8")Barfeed. 150mm (6") Chucking.
  • Barfeed : Sameca Monosam Hydraulic Barfeed System
  • Maximum speed : 5000 RPM
  • Accuracy : 8 microns

Mori-Seiki SL25 c/w Fanuc OTC control

  • Capacity : 67mm bar feed. 400mm (16") Chucking
  • Swarf Conveyor
  • Maximum speed : 3500 RPM
  • Accuracy : 10 microns



All machines are linked to a DNC system for offline editing and storage of programs running Vipterm software.




CNC Milling Capacity


Bridgeport VMC 800 machining centres incorporating a Heidenhain 370 controls and full in-cycle probing using infra-red technology.

1989 Bridgeport Interact 1 Mk 2 c/w Heidenhain 151 control

Axis travel : X = 18". Y = 12". Z = 5".

Bridgeport Interact 1 Mk 2 c/w Heidenhain 155 control with full graphics facility

Axis travel : X = 18". Y = 12". Z = 5".

Bridgeport MDI 1 c/w Heidenhain 131 control

Axis Travel : X = 18". Y = 12". Z = 5".

Haas Mini Mill c/w Haas Controller

40-taper Spindle
10-pocket Tool Changer
Direct Speed, Belt Drive
7.5 Horsepower
6,000rpm Vector Drive Spindle
914 x 305mm Table



All machines are linked to a DNC system for offline editing and storage of programs running Vipterm software and EZ Featuremill 2.1/2 D CAD/CAM software.




Manual Machining Facilities

Fabrication, Presswork and Sheet Metalwork

(1) 200 amp Portable TIG welding station

(1) 250 amp Manual arc Electric welding station

(2) 150 amp Manual arc Electric welding station

(1) Oxy-Acetylene welding and cutting station

(1) Bar and rod bender capacity 3" x 1/2"

(1) Denbigh No.4 Press

(2) Denbigh No.3 Press

(1) Gabro Box and Pan Folder Capacity 48" x 16 swg

(1) Edwards Guillotine, Capacity 48" x 16 swg

Manual Machine Shop

(1) Colchester Triumph 2500 Centre lathe

(2) Ward 7a Capstan Lathe

(1) Craven Horizontal Mill

(1) Centec Horizontal Mill

(1) Ajax Vertical Mill

(1) Induma Vertical Mill

(1) Meddings Cold saw

(1) Qualters & Smith Hacksaw

(2) Meca Turret Drills
